• VMP Low profile Articulating TV Wall Mount for 32 to 52 Inch
1 1

VMP Low profile Articulating TV Wall Mount for 32 to 52 Inch

SKU FP-XMLPAB

$229.95
$363.95 $229.95
Save $134.00 (37%)

Tax & shipping calculated at checkout

Ships same or next business day

Talk to a mount expert

800-585-8795

30-day returns

Easy & no hassle

Built to last

Heavy-gauge metal

The VMP FP-XMLPAB is a low profile articulating wall mount for 32 to 52 inch flat panel displays. It sits just 1.5 inches from the wall when closed and extends out to 16.2 inches, and it tilts, swivels, and levels so you can set a comfortable viewing angle in any room. The mount attaches to two studs about 16 inches apart, and the mounting rails accept a padlock to help secure the display against theft.

  • Holds most 32 to 52 inch flat panel displays
  • Load capacity up to 100 lbs
  • Maximum mounting hole pattern 600 mm wide by 400 mm tall (VESA)
  • Distance from wall 1.5 inches closed to 16.2 inches extended
  • Tilts from -2 degrees to +10 degrees for glare control
  • Swivels up to plus or minus 45 degrees
  • Post install level correction of plus or minus 3 degrees
  • Mounts to two wood studs approximately 16 inches apart or other suitable surface
  • Constructed of formed steel and aluminum with arc welds
  • Integrated cable management system and built in level
  • Mounting rails accept a padlock for added security, black powder coat finish

Product details

Screen size 32-52"
Max weight 100 lb · 45 kg
Tilt 2° up · 10° down
Mount distance 1.5-16.2" from wall

VESA mounting pattern

VESA is the spacing between the four bolt holes on the back of your TV. Screen sizes are a guideline - any TV whose bolt pattern fits this mount and whose weight is under the rating will work, even if the screen is larger. Enter what you measure below and we'll match it to the nearest standard size and check the fit.

VESA hole pattern shown to scale on the back of a display VESA mounting holes 200 to 600 mm wide and 200 to 412 mm tall, shown to scale on an approximately 52 inch 16:9 display.
200-412 mm 7.9-16.2"
200-600 mm 7.9-23.6"

shown to scale on a ~52" screen (16:9)

200-600 mm wide · 200-412 mm tall(7.9-23.6" wide · 7.9-16.2" tall)

Supported standards200×200VESA 200 by 200 mm, about 8 by 8 inches200×300VESA 200 by 300 mm, about 8 by 12 inches200×400VESA 200 by 400 mm, about 8 by 16 inches300×200VESA 300 by 200 mm, about 12 by 8 inches300×300VESA 300 by 300 mm, about 12 by 12 inches300×400VESA 300 by 400 mm, about 12 by 16 inches400×200VESA 400 by 200 mm, about 16 by 8 inches400×300VESA 400 by 300 mm, about 16 by 12 inches400×400VESA 400 by 400 mm, about 16 by 16 inches600×200VESA 600 by 200 mm, about 24 by 8 inches600×400VESA 600 by 400 mm, about 24 by 16 inches

Common standards within this hole range - not an exhaustive list.

Will my TV fit?

round to the nearest inch - close is fine, we'll match it to the standard size

enter your TV's spacing to check

How do I find my TV's pattern?

Find the four threaded holes on the back of your TV and measure between them - left-to-right and top-to-bottom, center to center. Round to the nearest inch. Or check your TV's manual, or search "[your model] VESA pattern".

Can't find it or not sure? Call us at 800-585-8795 or email sales@videomountstore.com - we can usually look up your TV's pattern faster than you can.
