  • LCD-2537C angled view of the silver ceiling mount: square ceiling plate, drop pole, and a tilting VESA plate with an adjustment knob
1 2

VMP LCD Ceiling Mount for 23 to 37" TV's/Monitors

SKU LCD-2537C

$96.95
$193.95 $96.95
Save $97.00 (50%)

Tax & shipping calculated at checkout

Ships same or next business day

Talk to a mount expert

800-585-8795

30-day returns

Easy & no hassle

Built to last

Heavy-gauge metal

The VMP LCD-2537C is a mid-size flat panel ceiling mount that holds a 25 to 37 inch display weighing up to 75 lbs. Its telescoping mast adjusts from 18 to 30 inches below the ceiling, so you can set the screen at the right viewing height. The head rotates a full 360 degrees at the ceiling and 240 degrees at the panel, plus a tilt range that helps aim the screen toward viewers below.

  • Holds 25 to 37 inch flat panel displays
  • Load capacity up to 75 lbs
  • Telescoping mast adjusts from 18 to 30 inches from the ceiling
  • Rotates 360 degrees at the ceiling and 240 degrees at the panel
  • Adjustable tilt from -5 to +20 degrees
  • Fits VESA 75 x 75, 100 x 100, 100 x 200, and 200 x 200 mm hole patterns
  • Includes two mounting plates, one for VESA 75 and 100 mm and one for VESA 100 x 200 and 200 mm patterns
  • Clip based cable management system keeps wiring tidy along the mast
  • Constructed primarily of tubular steel with arc welds and nylon filled nuts
  • Black powder coat finish, also available in silver powder coat

Product details

Screen size 23-37"
Max weight 75 lb · 34 kg
Tilt 5° up · 20° down
Mount distance 23.25-35" from ceiling

VESA mounting pattern

VESA is the spacing between the four bolt holes on the back of your TV. Screen sizes are a guideline - any TV whose bolt pattern fits this mount and whose weight is under the rating will work, even if the screen is larger. Enter what you measure below and we'll match it to the nearest standard size and check the fit.

VESA hole pattern shown to scale on the back of a display VESA mounting holes 75 to 200 mm wide and 75 to 200 mm tall, shown to scale on an approximately 37 inch 16:9 display.
75-200 mm 3-7.9"
75-200 mm 3-7.9"

shown to scale on a ~37" screen (16:9)

75-200 mm wide · 75-200 mm tall(3-7.9" wide · 3-7.9" tall)

Supported standards75×75VESA 75 by 75 mm, about 3 by 3 inches100×100VESA 100 by 100 mm, about 4 by 4 inches100×200VESA 100 by 200 mm, about 4 by 8 inches200×100VESA 200 by 100 mm, about 8 by 4 inches200×200VESA 200 by 200 mm, about 8 by 8 inches

Common standards within this hole range - not an exhaustive list.

Will my TV fit?

round to the nearest inch - close is fine, we'll match it to the standard size

enter your TV's spacing to check

How do I find my TV's pattern?

Find the four threaded holes on the back of your TV and measure between them - left-to-right and top-to-bottom, center to center. Round to the nearest inch. Or check your TV's manual, or search "[your model] VESA pattern".

Can't find it or not sure? Call us at 800-585-8795 or email sales@videomountstore.com - we can usually look up your TV's pattern faster than you can.
